The CQ Magnetic Drive Pump features a seal-less magnetic coupling design, ideal for safe handling of hazardous, corrosive, or high-purity fluids. Energy-efficient, low-maintenance, and compact, it excels in chemical, pharmaceutical, and food processing applications.
MOQ:
1Package:
CustomziedColor:
CustomziedMaterial:
Stainless Steel
Product Features
The CQ Magnetic Drive Pump integrates permanent magnetic coupling technology into centrifugal pumps,offering a rationally designed,advanced-engineered solution with full sealing,leak-free operation,and corrosion resistance,matching the advanced performance levels of similar foreign products.By replacing dynamic seals with static seals,the pump ensures complete sealing of flow components,eliminating leaks,drips,or spills common in traditional mechanical seals.Constructed from corrosion-resistant,high-strength engineering plastics,alumina ceramics,or stainless steel,it prevents contamination of the transported medium while maintaining durability.
Main Application
Compact in structure, aesthetically designed, lightweight, low-noise, and highly reliable, the CQ Magnetic Pump offers easy maintenance. Ideal for chemical, pharmaceutical, petroleum, electroplating, food, film and photographic processing, scientific research, and national defense industries, it efficiently handles acids, alkalis, oils, rare fluids, toxic liquids, volatile substances, and cooling water systems. Particularly suited for leakage-prone, flammable, or explosive fluids, this pump ensures safety and efficiency.
Structural Diagram
| 1 | Pump Casing | 2 | Static Ring |
| 3 | Rotating Ring | 4 | Impeller |
| 5 | Sealing Ring | 6 | Partition Plate |
| 7 | Isolation Sleeve | 8 | Outer Magnet Assembly |
| 9 | Inner Magnet Assembly | 10 | Pump Shaft |
| 11 | Shaft Sleeve | 12 | Connecting Bracket |
| 13 | Motor |
Installation and Use of Magnetic Pumps
(1) The magnetic pump should be installed horizontally and not vertically. The plastic pump body shall not bear the weight of the pipeline. In special cases where vertical installation is required, the motor must face upwards.
(2) When the liquid level being pumped is higher than the pump shaft centerline, just open the valve of the suction pipeline before starting. If the liquid level being pumped is lower than the pump shaft centerline, a foot valve needs to be installed in the pipeline.
(3) Before using the pump, an inspection should be carried out. The fan blades of the motor should rotate flexibly without jamming or abnormal noise, and all fasteners should be tightened.
(4) Check whether the rotation direction of the motor is consistent with the rotation direction mark of the magnetic pump.
(5) After the motor starts, slowly open the discharge valve. After the pump enters the normal working state, adjust the discharge valve to the required opening degree.
(6) Before stopping the pump, first close the discharge valve, and then close the suction pipe valve.
Others
A magnetic pump belongs to the new generation of centrifugal pumps. It is composed of a pump, a magnetic actuator, and a motor. Torque is transferred via magnetic force, thereby preventing leaks. This type of pump is corrosion-resistant and applicable to various industries such as the chemical and pharmaceutical industries.
Details
The TCH no-leakage stainless steel magnetic pump represents an advanced type of industrial pump. It is characterized by a full-seal design, which effectively eliminates the possibility of leakage. Constructed from stainless steel, it exhibits excellent corrosion resistance. The high-quality magnets incorporated within the pump ensure a reliable magnetic drive, making it well-suited for application in a diverse range of industries.
Details
The TCSF no-leakage lining fluorine magnetic pump is a remarkable device. It is lined with fluorine, which endows it with excellent corrosion resistance. The magnetic drive mechanism guarantees a leak-free operation, making it an ideal choice for the transfer of fluids in chemical and industrial applications.
Details
The no-leakage fluorine-lined magnetic pump is characterized by its high corrosion resistance, which is attributed to the fluorine lining. The magnetic drive mechanism ensures a hermetic seal, preventing any leakage, and making it suitable for a wide range of fluid transfer applications.
Details
The magnetic vacuum pump utilizes magnetic coupling for torque transmission. This eliminates the necessity for seals, thereby reducing the risks of leakage. It is well-suited for a wide range of vacuum applications.
Details
Chemical centrifugal force pump, with simple structure, converts rotational energy into hydrodynamic energy to transport various liquids. Widely used in multiple industries, it is energy-saving, durable, and has a long service life.
Details
The CQB Stainless Steel Magnetic Drive Centrifugal Pump is reliable, corrosion-resistant, and ideal for chemical, pharmaceutical industries.
Details
The THZWF fluorine axial flow pump is a high-quality pump specifically engineered for fluorine-related applications. Leveraging advanced technology, it boasts high efficiency and stable performance. This pump is capable of effectively handling fluorine-containing fluids, ensuring precise control of flow and head. To ensure long-term reliable operation in diverse industrial processes, the pump is constructed using corrosion-resistant materials.
